Aluminium 6012 | Product Overview
Introduction To Aluminium 6012
MOKSH TUBES & FITTINGS LLP is a trusted manufacturer, supplier, exporter, importer, and stockist of Aluminium Alloy 6012 products, including sheets, plates, coils, rods, and extrusions.
Aluminium 6012 is a heat-treatable wrought alloy primarily used in automotive and structural applications. Known for its good mechanical properties, corrosion resistance, and excellent machinability, 6012 offers a balanced combination of strength, ductility, and formability. It is commonly used where lightweight and good surface finish are required, making it suitable for panels, body parts, and other structural components.
Download Alluminium Alloy 6012 Datasheet
Get the complete Alluminium Alloy 6012 datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
Aluminium 6012 Specifications (AA6012 / UNS A96012)
| Category | Details |
|---|---|
| Grade | Aluminium 6012 / AA6012 / UNS A96012 |
| Type | Heat-treatable wrought aluminium alloy |
| Typical Chemical Composition | Si 0.8–1.2%, Mg 0.45–0.8%, Cu 0.2–0.6% |
| Conditions | O, T4, T6 |
| Heat Treatment | Solution Heat Treatment + Artificial Aging |
| Testing | Tensile, Hardness, Chemical, UT (on request) |
| Certification | EN 10204 3.1 / 3.2 (MTC Available) |
Chemical Composition – Aluminium Alloy 6012
| Element | Composition (%) |
|---|---|
| Silicon (Si) | 0.8 – 1.2 |
| Magnesium (Mg) | 0.45 – 0.8 |
| Copper (Cu) | 0.2 – 0.6 |
| Manganese (Mn) | 0.1 – 0.4 |
| Iron (Fe) | 0.5 max |
| Zinc (Zn) | 0.2 max |
| Titanium (Ti) | 0.1 max |
| Chromium (Cr) | 0.1 max |
| Aluminium (Al) | Balance |
Aluminium 6012 is prized for its excellent machinability, moderate strength, and good corrosion resistance.
Physical Properties – Aluminium Alloy 6012
| Property | Imperial | Metric |
|---|---|---|
| Density | 0.097 lb/in³ | 2.70 g/cm³ |
| Melting Range | 1140 – 1220 °F | 615 – 660 °C |
| Modulus of Elasticity | 10.1 × 10³ ksi | 70 GPa |
| Thermal Conductivity | — | 151 W/m·K |
| Electrical Conductivity | 36% IACS | — |
Heat Treatment – Aluminium Alloy 6012
| Heat Treatment Process | Temperature Range | Cooling / Procedure | Notes |
|---|---|---|---|
| Solution Heat Treatment | 500 – 520 °C | Water quench | Required to achieve T6 strength |
| Artificial Aging (T6) | 160 – 190 °C | Air cool | Enhances tensile strength & hardness |
| Annealing (O Temper) | 340 – 400 °C | Furnace cool | Restores full ductility for forming |
| Stress Relieving | 150 – 200 °C | Air cool | Reduces internal stresses from machining |
Mechanical Properties – Aluminium Alloy 6012
| Property | Annealed | Hot Finished | Cold Drawn | Hot Rolled | Sheet (T6) |
|---|---|---|---|---|---|
| Tensile Strength (MPa) | 125 – 195 | 240 – 310 | 275 – 330 | 240 – 310 | 310 – 345 |
| Yield Strength (MPa) | 70 – 125 | 190 – 240 | 240 – 290 | 205 – 275 | 275 – 310 |
| Elongation (%) | 14 – 25 | 10 – 18 | 8 – 12 | 10 – 15 | 8 – 10 |
| Brinell Hardness | 35 – 50 HB | 70 – 85 HB | 80 – 90 HB | 75 – 85 HB | 85 – 95 HB |
| Rockwell Hardness | 20 – 30 B | 50 – 60 B | 55 – 65 B | 50 – 60 B | 60 – 65 B |
International Standards & Equivalent Grades – Aluminium 6012
| Standard | Equivalent Grade |
|---|---|
| ASTM | B209 (Sheets & Plates) |
| AMS | 4218 |
| ISO | 6361 |
| EN | AW-6012 |
Products in Aluminium Alloys
Aluminium 6012 is available in various mill forms such as
✔
Seamless Pipes
✔
Welded Pipes (ERW & EFW)
✔
Tubes (Capillary, U-Bend)
✔
Sheets & Plates
✔
Coils & Strips
✔
Round Bars, Flat Bars, Hex Bars, Square Bars
✔
Pipe Fittings (Elbows, Tees, Reducers, Caps, Stub Ends)
✔
Flanges (Weld Neck, Slip-On, Blind, Socket Weld, Threaded)
✔
Fasteners (Bolts, Nuts, Screws, Washers, Studs)
✔
Custom Fabricated Components
We supply Aluminium 6012 materials in accordance with the most stringent industry standards:
Uses and Advantages
Good balance of strength, ductility, and machinability
Excellent corrosion resistance in atmospheric conditions
Lightweight and easily fabricated
Good surface finish and weldability
Suitable for anodizing and other surface treatments
Applications of Aluminium 6012
Aluminium 6012 is widely used in applications requiring good machinability, moderate strength, and corrosion resistance:
Automotive Industry
Body panels, structural components, and chassis parts where lightweight and strength are critical.
Electrical Components
Used for electrical housings and connectors due to its good conductivity and corrosion resistance.
Structural Applications
Frames, supports, and architectural components requiring moderate strength and corrosion resistance.
Consumer Goods
Used in appliances, sports equipment, and furniture for its surface finish and workability.
WHY CHOOSE US?
Aluminium Alloy 6012 Price per kg in India
Typical Range: ₹290 – ₹450 per kg
(Price varies by OD, wall thickness, form, and finish)
Contact us for exact quotation based on size and quantity.
FAQ's
What is Aluminium Alloy 6012 and what are its key properties?
Aluminium Alloy 6012 is a heat treatable wrought aluminum alloy designed for automotive, structural, and general engineering applications. It offers an excellent balance of strength, ductility, machinability, and corrosion resistance. The alloy is widely used where lightweight material with good surface finish is required.
What are the common applications of Aluminium 6012?
Aluminium 6012 is used in a variety of industries, including:
- Automotive: Body panels, structural components, chassis parts.
- Electrical: Housings, connectors, and conductive component.
- Structural: Frames, supports, and architectural fittings.
- Consumer Goods: Sports equipment, appliances, and furniture.
- Industrial Fabrication: Extrusions, plates, and rods requiring corrosion resistance and strength.
Is Aluminium Alloy 6012 suitable for welding and surface treatments?
Yes, Aluminium 6012 provides good weldability and is suitable for anodizing and other surface treatments, making it ideal for both functional and decorative applications. It also delivers a smooth surface finish, which is highly beneficial in automotive and consumer product manufacturing.
What are the main advantages of Aluminium 6012?
Key benefits of Aluminium Alloy 6012 include:
- Balanced strength and ductility for versatile applications.
- Excellent corrosion resistance in atmospheric environments.
- Outstanding machinability and workability.
- Lightweight with high formability.
- Suitable for anodizing and surface finishing.
What Aluminium 6012 products does Moksh Tubes & Fittings LLP supply?
Moksh Tubes & Fittings LLP offers a wide range of Aluminium 6012 products, including:
