Aluminium 6082-T6 | Product Overview
Introduction To Aluminium 6082
MOKSH TUBES & FITTINGS LLP is a manufacturer, supplier, exporter, importer, and stockist of Aluminium Alloy 6082-T6 products including plates, sheets, tubes, bars, rods, and extrusions.
Aluminium 6082 is a medium-strength alloy in the 6000 series, known for its excellent corrosion resistance, good machinability, and superior mechanical properties. The T6 temper refers to solution heat-treated and artificially aged condition, providing enhanced strength and durability. 6082-T6 is widely used in structural applications and marine environments, especially in Europe, where it is preferred for structural and transport sectors.
Download Alluminium Alloy 6083 T6 Datasheet
Get the complete Alluminium Alloy 6083 T6 datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
Aluminium 6082-T6 Specifications (AA6082 / UNS A96082)
| Category | Details |
|---|---|
| Grade | AA 6082 / 6082-T6 / UNS A96082 |
| Type | Heat-treatable wrought aluminium alloy |
| Typical Chemical Composition | Si 0.7–1.3%, Mg 0.6–1.2%, Mn 0.4–1.0% |
| Conditions | O, T4, T5, T6 |
| Heat Treatment | Solution Heat Treatment + Artificial Aging |
| Testing | Tensile, Hardness, Chemical, UT (on request) |
| Certification | EN 10204 3.1 / 3.2 (MTC Available) |
Chemical Composition – Aluminium Alloy 6082-T6
| Element | Composition (%) |
|---|---|
| Silicon (Si) | 0.7 – 1.3 |
| Magnesium (Mg) | 0.6 – 1.2 |
| Manganese (Mn) | 0.4 – 1.0 |
| Iron (Fe) | 0.5 max |
| Copper (Cu) | 0.1 max |
| Chromium (Cr) | 0.25 – 0.45 |
| Zinc (Zn) | 0.2 max |
| Titanium (Ti) | 0.1 max |
| Aluminium (Al) | Balance |
6082-T6 is often referred to as the structural aluminium alloy due to its superior strength.
Physical Properties – Aluminium 6082-T6
| Property | Imperial Units | Metric Units |
|---|---|---|
| Density | 0.098 lb/in³ | 2.70 g/cm³ |
| Melting Range | 1070–1220 °F | 575–660 °C |
| Modulus of Elasticity | 10 × 10³ ksi | 69 GPa |
| Thermal Conductivity | — | 165 W/m·K |
| Electrical Conductivity | 30% IACS | — |
Heat Treatment – Aluminium Alloy 6082-T6
| Heat Treatment Process | Temperature Range | Cooling / Procedure | Notes |
|---|---|---|---|
| Solution Heat Treatment | 515 – 530°C | Water quench | Prepares alloy for T6 aging |
| Artificial Aging (T6) | 170 – 185°C | Air cool | Maximum strength by precipitation hardening |
| Annealing (O Temper) | 350 – 410°C | Furnace cool | Restores ductility |
| Stress Relieving | 150 – 200°C | Air cool | Reduces residual stresses |
Mechanical Properties – Aluminium 6082-T6
| Property | Annealed | Hot Finished | Cold Drawn | Hot Rolled | Sheet (T6) |
|---|---|---|---|---|---|
| Tensile Strength (MPa) | 115 – 165 | 240 – 310 | 260 – 325 | 205 – 303 | 310 – 380 |
| Yield Strength (MPa) | 70 – 100 | 210 – 275 | 235 – 290 | 170 – 260 | 275 – 345 |
| Elongation (%) | 12 – 20 | 6 – 10 | 5 – 10 | 8 – 12 | 8 – 12 |
| Brinell Hardness | 45 – 60 HB | 80 – 95 HB | 85 – 100 HB | 70 – 90 HB | 95 – 100 HB |
| Rockwell Hardness | 25 – 35 B | 40 – 55 B | 45 – 60 B | 35 – 50 B | 60 – 65 B |
6082-T6 provides the highest strength of all 6000-series extruded aluminium alloys.
International Standards & Equivalent Grades – Aluminium 6082-T6
| Standard | Equivalent Grade |
|---|---|
| BS EN | 755-2 |
| ASTM | B221 (Extrusions) |
| ISO | 6361 |
| EN | AW-6082 |
| JIS | H4000 Series |
Products in Aluminium Alloys
Aluminium 6082-T6 is commonly supplied as:
✔
Seamless Pipes
✔
Welded Pipes (ERW & EFW)
✔
Tubes (Capillary, U-Bend)
✔
Sheets & Plates
✔
Coils & Strips
✔
Round Bars, Flat Bars, Hex Bars, Square Bars
✔
Pipe Fittings (Elbows, Tees, Reducers, Caps, Stub Ends)
✔
Flanges (Weld Neck, Slip-On, Blind, Socket Weld, Threaded)
✔
Fasteners (Bolts, Nuts, Screws, Washers, Studs)
✔
Custom Fabricated Components
We supply Aluminium 6082-T6 materials in accordance with the most stringent industry standards:
Uses and Advantages
High strength and good corrosion resistance
Excellent machinability and weldability
Good fatigue resistance and toughness
Suitable for structural and transport applications
Good surface finish and anodizing capability
Applications of Aluminium 6082-T6
Aluminium 6082-T6 is widely used for its high strength, good corrosion resistance, and weldability in:
Structural Applications
Automotive and aerospace parts, trailers, and vehicle frames due to its lightweight and durability.
Marine Industry
Boat hulls, decks, and marine fittings exposed to saltwater environments.
General Engineering
Machinery parts, pipelines, and frames requiring strength and corrosion resistance.
WHY CHOOSE US?
Aluminium Alloy 6082-T6 Price per kg in India
Typical Range: ₹320 – ₹500 per kg
(Price varies by OD, wall thickness, form, and finish)
Contact us for exact quotation based on size and quantity.
FAQ's
What is Aluminium Alloy 6082-T6 used for?
Aluminium 6082-T6 is widely used in structural, marine, automotive, and aerospace applications due to its high strength, excellent corrosion resistance, and good machinability. Common uses include bridges, vehicle frames, boat hulls, cranes, and heavy duty equipment.
What are the advantages of Aluminium 6082-T6?
The main advantages of Aluminium 6082-T6 are its high tensile strength, superior corrosion resistance, excellent weldability, and good fatigue performance. It also offers a good surface finish for anodizing, making it suitable for both structural and decorative purposes.
How strong is Aluminium 6082-T6 compared to other aluminium alloys?
Aluminium 6082-T6 is considered the strongest alloy in the 6000 series, with a tensile strength of 310–380 MPa and a yield strength of 275–345 MPa. It is stronger than 6061 and offers better machinability, making it a preferred choice in engineering and transport industries.
Can Aluminium 6082-T6 be welded and machined easily?
Yes. Aluminium 6082-T6 offers excellent weldability with common welding techniques such as MIG and TIG. It also has superior machinability compared to many other alloys, making it ideal for precision engineering and custom fabrication.
Where can I buy high-quality Aluminium 6082-T6 products in India?
You can purchase premium quality Aluminium 6082-T6 sheets, plates, tubes, pipes, bars, and extrusions from Moksh Tubes & Fittings LLP, a leading manufacturer, supplier, exporter, and stockist in India. The company provides custom solutions, international quality standards, and timely deliveries.
