Stainless Steel 316Ti | Product Overview
Introduction To Austenitic Stainless Steel 316Ti
MOKSH TUBES & FITTINGS LLP is a prominent manufacturer, supplier, exporter, importer, and stockist of Austenitic Stainless Steel 316Ti products such as pipes & tubes, sheets, plates, bars, and fittings.
Austenitic Stainless Steel 316Ti, is a stabilized version of 316 stainless steel with titanium added to improve resistance to intergranular corrosion. It maintains excellent corrosion resistance, especially in chloride and acidic environments, and offers superior high-temperature strength. The titanium content stabilizes the alloy against carbide precipitation during welding, making it ideal for high-temperature and corrosive service conditions in chemical, petrochemical, and power industries.
Download Austentic Stainles Steel 316T Datasheet
Get the complete Austentic Stainles Steel 316T datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
Technical Specifications – Stainless Steel 316Ti (UNS S31635 / EN 1.4571)
| Category | Details |
|---|---|
| Material | Austenitic Stainless Steel 316Ti |
| UNS No. | S31635 |
| EN / DIN | 1.4571 |
| Alloy Type | Titanium-Stabilized Austenitic SS |
| Chromium | 16 – 18 % |
| Nickel | 10 – 14 % |
| Molybdenum | 2 – 3 % |
| Stabilizing Element | Titanium (Ti) |
| Magnetic Properties | Non-Magnetic |
| Heat Treatable | ❌ No |
| Strengthening Method | Cold Working |
| Intergranular Corrosion | Excellent |
| Chloride Resistance | Very Good |
| Typical Use | High-Temperature & Corrosive Environments |
Chemical Composition of Stainless Steel 316Ti
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.08 |
| Chromium (Cr) | 16.0 – 18.0 |
| Nickel (Ni) | 10.0 – 14.0 |
| Molybdenum (Mo) | 2.0 – 3.0 |
| Titanium (Ti) | 0.5 – 0.7 |
| Manganese (Mn) | ≤ 2.0 |
| Silicon (Si) | ≤ 0.75 |
| Phosphorus (P) | ≤ 0.045 |
| Sulfur (S) | ≤ 0.03 |
| Nitrogen (N) | ≤ 0.10 |
Physical Properties of Stainless Steel 316Ti
| Property | Imperial Units | Metric Units |
|---|---|---|
| Density | 0.289 lb/in³ | 8.0 g/cm³ |
| Melting Point | 2550 – 2650 °F | 1399 – 1454 °C |
| Modulus of Elasticity | 28 × 10³ ksi | 193 GPa |
| Poisson’s Ratio | 0.27 | — |
Heat Treatment & Fabrication of Stainless Steel 316Ti
| Process | Temperature Range | Purpose |
|---|---|---|
| Solution Annealing | 1000 – 1100 °C | Restore corrosion resistance |
| Cooling | Water / Rapid Air | Prevent sensitization |
| Stress Relieving | 300 – 450 °C | Reduce residual stress |
| Cold Working | — | Increase strength |
| Welding | TIG / MIG / SMAW | Excellent weldability |
📌 SS 316Ti is preferred over SS 316 for high-temperature welded applications due to titanium stabilization.
Mechanical Properties of Stainless Steel 316Ti (Annealed)
| Property | Annealed | Cold-Drawn | Sheet |
|---|---|---|---|
| Tensile Strength | 485 – 620 MPa | 550 – 760 MPa | 515 – 690 MPa |
| Yield Strength (0.2%) | 205 – 310 MPa | 310 – 485 MPa | 240 – 415 MPa |
| Elongation | 40 – 60 % | 20 – 40 % | 35 – 55 % |
| Brinell Hardness | 120 – 180 | 160 – 210 | 140 – 190 |
| Rockwell Hardness | 80 – 95 B | 90 – 105 B | 85 – 95 B |
Available Forms & Size Range – Stainless Steel 316Ti
| Product Form | Size Range |
|---|---|
| Pipes & Tubes | OD 6 – 600 mm, WT 0.8 – 40 mm |
| Sheets & Plates | 0.5 – 100 mm |
| Coils & Strips | 0.1 – 6 mm |
| Bars (Round / Flat / Hex) | Ø 6 – 350 mm |
| Wire & Mesh | Standard & custom sizes |
| Fittings & Flanges | ASME / DIN standards |
| Custom Components | As per drawing |
International Standards & Equivalent Grades – SS 316Ti
| Standard | Equivalent Grade |
|---|---|
| UNS | S31635 |
| ASTM | A240, A312, A276 |
| ASME | SA240, SA312, SA276 |
| EN | 1.4571 |
| DIN | X6CrNiMoTi17-12-2 |
| JIS | SUS 316Ti |
| BS | 320S31 |
| ISO | X6CrNiMoTi17-12-2 |
Products in Austenitic Stainless Steel 316Ti
Austenitic Stainless Steel 316Ti is available in:
Austenitic Stainless Steel 316Ti products are produced to the following global standards:
Uses and Advantages
Superior resistance to intergranular corrosion due to titanium stabilization
Excellent corrosion resistance in chloride and acidic environments
High strength retention at elevated temperatures
Good weldability and formability
Suitable for high-temperature applications up to 800°C
Applications of Austenitic Stainless Steel 316Ti
Austenitic Stainless Steel 316Ti is widely used in industries and environments requiring resistance to high temperature and corrosive media, including:
Chemical and Petrochemical Plants
Process vessels, heat exchangers, and piping exposed to acidic and chloride environments.
Power Generation
Components exposed to high temperatures such as boiler tubes, superheaters, and heat exchangers.
Marine Applications
Marine hardware, pumps, and valves due to its resistance to saltwater corrosion and high strength.
Pharmaceutical and Food Processing
Equipment requiring excellent corrosion resistance and hygienic properties.
Automotive and Aerospace
Exhaust components and engine parts exposed to elevated temperatures.
WHY CHOOSE US?
STAINLESS STEEL 316Ti PRICE PER KG (INDIA)
Typical Range: ₹390 – ₹720 per kg
(Price varies by OD, wall thickness, form, and finish)
Contact us for exact quotation based on size and quantity.
FAQ's
What is Austenitic Stainless Steel 316Ti and how is it different from 316 stainless steel?
Austenitic Stainless Steel 316Ti is a titanium stabilized version of SS 316, designed to resist intergranular corrosion caused by carbide precipitation during welding. While both alloys offer excellent corrosion resistance in chloride and acidic environments, 316Ti provides better high temperature strength and stability, making it ideal for continuous service up to 800°C.
What are the main properties of Stainless Steel 316Ti?
SS 316Ti is known for:
- Superior resistance to intergranular corrosion due to titanium stabilization.
- Excellent performance in chloride and acidic environments.
- High strength retention at elevated temperatures.
- Good weldability and fabrication properties.
- Suitability for hygienic and high temperature applications.
Where is Stainless Steel 316Ti commonly used?
316Ti stainless steel is widely used in industries such as:
- Chemical & petrochemical plants (vessels, piping, heat exchangers).
- Power generation (boiler tubes, superheaters, turbines).
- Marine environments (pumps, valves, and seawater exposed components).
- Pharmaceutical & food processing (sanitary fittings and hygienic equipment).
- Automotive & aerospace (exhaust systems and high-temperature engine parts).
Why is Stainless Steel 316Ti preferred for high-temperature applications?
The titanium content in SS 316Ti prevents carbide precipitation during welding and prolonged heating, which enhances resistance to intergranular corrosion. This stabilization allows it to maintain mechanical strength and corrosion resistance even at temperatures up to 800°C, making it ideal for power plants, heat exchangers, and chemical processing equipment.
Who is the trusted supplier of Stainless Steel 316Ti in India?
Moksh Tubes & Fittings LLP is a leading manufacturer, supplier, exporter, importer, and stockist of Stainless Steel 316Ti products. They offer a wide range of pipes, tubes, sheets, plates, bars, flanges, fittings, and fasteners manufactured to international standards. With custom sizing, technical support, global supply, and competitive pricing, Moksh Tubes & Fittings LLP is a reliable partner for industries worldwide.
