Product Overview
Introduction to Nitinol Nickel-Titanium Alloy
MOKSH TUBES & FITTINGS LLP is a leading manufacturer, exporter, importer, stockist, and supplier of Nitinol products in a variety of forms including wires, rods, sheets, tubes, springs, strips, and customized components. Nitinol (Nickel Titanium Naval Ordnance Laboratory) is a unique metal alloy primarily composed of nickel and titanium, widely known for its two remarkable properties: Shape Memory Effect (SME) and Superelasticity.
Nitinol's ability to return to a predetermined shape when heated and its exceptional elasticity under stress make it an ideal material for a variety of medical, industrial, and aerospace applications. It also offers excellent corrosion resistance, biocompatibility, and fatigue resistance, especially under cyclic loading environments.
Download Hard To Find Special Alloy Nitinol Datasheet
Get the complete Hard To Find Special Alloy Nitinol datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
NITINOL Specifications (Nickel–Titanium Alloy)
| Category | Details |
|---|---|
| Material Name | Nitinol (Nickel–Titanium Alloy) |
| UNS Designation | N01555 |
| Composition | Ni 54.5–57.0%, Ti Balance |
| Density | 6.45 g/cm³ |
| Melting Range | 1400 – 1480 °C |
| Magnetic Property | Non-Magnetic |
| Corrosion Resistance | Excellent |
| Biocompatibility | Excellent (Medical Grade) |
| Shape Memory Effect | ✔ Yes |
| Superelasticity | ✔ Yes |
| Heat Treatable | ✔ Yes (Transformation tuning) |
Chemical Composition of Nitinol
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 54.5 – 57.0 |
| Titanium (Ti) | Balance |
| Carbon (C) | ≤ 0.05 |
| Oxygen (O) | ≤ 0.05 |
| Hydrogen (H) | ≤ 0.005 |
| Nitrogen (N) | ≤ 0.01 |
| Iron (Fe) | ≤ 0.05 |
Physical Properties of Nitinol
| Property | Imperial Units | Metric Units |
|---|---|---|
| Density | 0.30 lb/in³ | 6.45 g/cm³ |
| Melting Range | 2550 – 2700 °F | 1400 – 1480 °C |
| Elastic Modulus (Tension) | 7.5 – 30 × 10³ ksi | 50 – 207 GPa |
| Elastic Modulus (Compression) | Similar to tension | Similar to tension |
| Poisson’s Ratio | 0.33 | — |
| Curie Temperature | 70 – 220 °F | 20 – 105 °C |
Heat Treatment & Transformation Control – Nitinol
| Process | Temperature Range | Purpose |
|---|---|---|
| Shape Setting | 400 – 550 °C | Fixes permanent shape memory |
| Annealing | 600 – 800 °C | Improves ductility & formability |
| Aging / Precipitation | 350 – 500 °C | Adjusts transformation temperature |
| Stress Relieving | 300 – 400 °C | Reduces residual stresses |
| Cold Work + Heat Treat | — | Enhances superelastic behavior |
📌 Transformation temperature (Af) can be precisely engineered for medical or industrial applications.
Mechanical Properties of Nitinol
| Property | Annealed | Hot-Finished | Cold-Drawn |
|---|---|---|---|
| Tensile Strength | 480–690 MPa | 620–830 MPa | 900–1100 MPa |
| Yield Strength (0.2%) | 210–345 MPa | 415–550 MPa | 690–900 MPa |
| Elongation | 10–30% | 8–20% | 5–10% |
| Brinell Hardness | 150–200 | 200–300 | 300–350 |
| Rockwell Hardness | 60–70 B | 70–80 B | 80–85 B |
Available Forms & Size Range – Nitinol
| Product Form | Typical Size Range |
|---|---|
| Wires | 0.05 – 6.0 mm |
| Tubes | OD 0.8 – 25 mm; WT 0.1 – 2.5 mm |
| Sheets & Plates | 0.2 – 10 mm |
| Strips & Foils | 0.03 – 2.0 mm |
| Rods & Bars | 3 – 100 mm |
| Springs | As per design |
| Custom Components | CNC / Laser-cut / Medical grade |
International Standards & Equivalent Grades – Nitinol
| Standard / Organization | Equivalent / Description |
|---|---|
| UNS | N01555 |
| ASTM | ASTM F2063 (Medical Grade) |
| ASTM | ASTM F2005 (Transformation Temperature) |
| AMS | AMS 5898 (Aerospace) |
| ISO | ISO 5832-11 (Implant Grade) |
| DIN | DIN 17856 |
| EN | EN ISO 5832-11 |
Products in Nitinol
Nitinol is commonly supplied as:
✔
Seamless Pipes
✔
Welded Pipes (ERW & EFW)
✔
Tubes (Capillary, U-Bend)
✔
Sheets & Plates
✔
Coils & Strips
✔
Round Bars, Flat Bars, Hex Bars, Square Bars
✔
Pipe Fittings (Elbows, Tees, Reducers, Caps, Stub Ends)
✔
Flanges (Weld Neck, Slip-On, Blind, Socket Weld, Threaded)
✔
Fasteners (Bolts, Nuts, Screws, Washers, Studs)
✔
Custom Fabricated Components
We supply Nitinol materials in accordance with the most stringent industry standards:
Uses and Advantages
Shape memory and superelastic behavior enable compact, adaptive designs
Excellent corrosion and fatigue resistance
Biocompatible – suitable for long-term medical implants
High strength-to-weight ratio
Responds predictably to thermal and mechanical stimuli
Applications of Nitinol
Nitinol’s extraordinary properties make it highly versatile across numerous sectors:
Medical & Biomedical Devices
Used extensively in stents, guidewires, orthodontic archwires, bone staples, and filters due to its biocompatibility and superelastic behavior.
Aerospace & Defense
Used in actuators, couplings, and vibration dampers due to its fatigue resistance and thermal responsiveness.
Robotics & Automation
Ideal for motion-control systems, micro-actuators, and adaptive mechanisms.
Consumer Electronics
Applied in eyeglass frames, cellphone actuators, and flexible antenna components.
Industrial Equipment
Deployed in valves, connectors, seals, and temperature-sensitive fasteners that rely on the shape memory effect.
Oil & Gas Industry
Utilized in downhole tools and sealing components that undergo thermal cycling.
WHY CHOOSE US?
Nitinol Price per kg in India
Typical Range: ₹18,000 – ₹45,000 per kg
(Price varies by OD, wall thickness, form, and finish)
Contact us for exact quotation based on size and quantity.
FAQ's
What is Nitinol and why is it special?
Nitinol is a nickel titanium alloy notable for its Shape Memory Effect and Superelasticity, allowing it to return to a preset shape when heated and endure large strains without permanent deformation.
Which forms of Nitinol products are available?
Nitinol is supplied as seamless and welded pipes, tubes, sheets, plates, coils, strips, round/flat/hex/square bars, pipe fittings, flanges, fasteners, springs, and custom components.
What are the key advantages of Nitinol?
Nitinol offers shape memory, superelasticity, high corrosion and fatigue resistance, biocompatibility for medical implants, and predictable responses to thermal and mechanical stimuli.
In which industries is Nitinol used?
Nitinol is used in medical devices (stents, guidewires, orthodontics), aerospace and defense (actuators, vibration dampers), robotics, consumer electronics (eyeglass frames, actuators), industrial equipment, and oil & gas applications.
Why choose MOKSH TUBES & FITTINGS for Nitinol products?
We provide a wide range of standard and custom Nitinol components with precision manufacturing, stringent quality controls, ASTM and medical-grade compliance, global shipping, and prompt delivery.
