European Structural Columns
European Structural Columns are vertical structural steel members designed to transfer loads from beams, floors, roofs and other structural components to the foundation or supporting structure.
Common European column profiles include:
- HEA Columns – Wide-flange H-shaped structural sections used for general structural applications.
- HEB Columns – Heavier H-shaped sections used where greater section capacity and rigidity are required.
- HEM Columns – Heavy H-shaped sections designed for applications requiring substantial structural capacity.
- Other EN Column Profiles – As specified by the applicable European standard and project requirements.
The appropriate column section is selected according to axial loading, column height, structural stability, section properties, connection requirements, material grade and engineering design.
European Structural Columns are specified according to applicable European Standards (EN), with the material grade selected according to the required mechanical properties and project specification. Common structural steel grades may include S235JR, S275JR, S355JR and S355J2, subject to the applicable specification.
At Moksh Tubes & Fittings LLP, we support European Structural Column requirements based on customer drawings, technical specifications and project requirements. Customers can specify the required column designation, section dimensions, material grade, length and quantity.
European Structural Columns can also be used together with European Structural Angles, Channels, Beams and Hollow Sections to create complete steel building frameworks and fabricated structural assemblies.
For an accurate quotation, customers can provide their required column designation, section dimensions, grade, length and quantity, along with project drawings or technical documentation where required.
Download European Structural Columns Datasheet
Get the complete European Structural Columns datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
Specifications
European Structural Columns are available in different column profiles, section depths, flange widths, web thicknesses, flange thicknesses, lengths and structural steel grades according to applicable European Standards (EN) and project specifications.
| Category | Details |
|---|---|
| Product | European Structural Columns |
| Profiles | HEA / HEB / HEM & Other Applicable EN Sections |
| Profile Type | H-Shaped Structural Sections |
| Material | Structural Steel / Carbon Steel |
| Standards | Applicable European Standards (EN) |
| Grades | S235JR / S275JR / S355JR / S355J2 & Other Applicable Grades |
| Section Depth | Various Standard Sizes |
| Flange Width | As per Selected Column Section |
| Web Thickness | As per Selected Section |
| Flange Thickness | As per Selected Section |
| Length | Standard Lengths / Cut-to-Length |
| Surface | Mill Finish / As Specified |
| Supply Form | Individual Sections / Bundles |
| Customization | Section, Size, Grade, Length & Quantity as Required |
| Applications | Construction, Industrial, Infrastructure, Fabrication & Engineering |
HEA Columns
HEA sections are wide-flange H-shaped structural sections commonly used as columns and other load-bearing members in buildings, industrial structures and engineered steel frameworks.
HEB Columns
HEB sections are heavier H-shaped structural sections that can be considered for applications requiring greater section capacity and rigidity according to engineering design.
HEM Columns
HEM sections are heavier European H-shaped structural sections intended for applications requiring substantial structural capacity and stiffness.
EN Standards
European Structural Columns should be specified according to the applicable EN standard and project specification. The relevant standard depends on the column profile, dimensions, material grade and intended application.
Column Dimensions
European Structural Columns are generally identified by their designation and section dimensions, including:
- Overall Section Depth
- Flange Width
- Web Thickness
- Flange Thickness
- Cross-Sectional Area
- Section Weight
- Required Length
Supply Requirements
For an accurate quotation, customers should provide:
- Column Type / Designation
- Section Depth & Flange Width
- Web & Flange Thickness
- Material Grade
- Required Length
- Quantity
- Applicable EN Standard
- Project Specification, if applicable
Moksh Tubes & Fittings LLP can support standard and project-based requirements for European Structural Columns, subject to product availability and agreed specifications.
Size & Weight Chart
HEA – European Standard Wide Flange Columns
| Section | Height h (mm) | Width b (mm) | Web Thickness tw (mm) | Flange Thickness tf (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEA 100 | 96 | 100 | 5.0 | 8.0 | 16.7 |
| HEA 120 | 114 | 120 | 5.0 | 8.0 | 19.9 |
| HEA 140 | 133 | 140 | 5.5 | 8.5 | 24.7 |
| HEA 160 | 152 | 160 | 6.0 | 9.0 | 30.4 |
| HEA 180 | 171 | 180 | 6.0 | 9.5 | 35.5 |
| HEA 200 | 190 | 200 | 6.5 | 10.0 | 42.3 |
| HEA 220 | 210 | 220 | 7.0 | 11.0 | 50.5 |
| HEA 240 | 230 | 240 | 7.5 | 12.0 | 60.3 |
| HEA 260 | 250 | 260 | 7.5 | 12.5 | 68.2 |
| HEA 280 | 270 | 280 | 8.0 | 13.0 | 76.4 |
| HEA 300 | 290 | 300 | 8.5 | 14.0 | 88.3 |
| HEA 320 | 310 | 300 | 9.0 | 15.5 | 97.6 |
| HEA 340 | 330 | 300 | 9.5 | 16.5 | 105.0 |
| HEA 360 | 350 | 300 | 10.0 | 17.5 | 112.0 |
| HEA 400 | 390 | 300 | 11.0 | 19.0 | 125.0 |
| HEA 450 | 440 | 300 | 11.5 | 21.0 | 140.0 |
| HEA 500 | 490 | 300 | 12.0 | 23.0 | 155.0 |
| HEA 550 | 540 | 300 | 12.5 | 24.0 | 166.0 |
| HEA 600 | 590 | 300 | 13.0 | 25.0 | 178.0 |
HEB – European Standard Heavy Wide Flange Columns
| Section | Height h (mm) | Width b (mm) | Web Thickness tw (mm) | Flange Thickness tf (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEB 100 | 100 | 100 | 6.0 | 10.0 | 20.4 |
| HEB 120 | 120 | 120 | 6.5 | 11.0 | 26.7 |
| HEB 140 | 140 | 140 | 7.0 | 12.0 | 33.7 |
| HEB 160 | 160 | 160 | 8.0 | 13.0 | 42.6 |
| HEB 180 | 180 | 180 | 8.5 | 14.0 | 51.2 |
| HEB 200 | 200 | 200 | 9.0 | 15.0 | 61.3 |
| HEB 220 | 220 | 220 | 9.5 | 16.0 | 71.5 |
| HEB 240 | 240 | 240 | 10.0 | 17.0 | 83.2 |
| HEB 260 | 260 | 260 | 10.0 | 17.5 | 93.0 |
| HEB 280 | 280 | 280 | 10.5 | 18.0 | 103.0 |
| HEB 300 | 300 | 300 | 11.0 | 19.0 | 117.0 |
| HEB 320 | 320 | 300 | 11.5 | 20.5 | 127.0 |
| HEB 340 | 340 | 300 | 12.0 | 21.5 | 134.0 |
| HEB 360 | 360 | 300 | 12.5 | 22.5 | 142.0 |
| HEB 400 | 400 | 300 | 13.5 | 24.0 | 155.0 |
| HEB 450 | 450 | 300 | 14.0 | 26.0 | 171.0 |
| HEB 500 | 500 | 300 | 15.5 | 28.0 | 187.0 |
| HEB 550 | 550 | 300 | 15.0 | 29.0 | 199.0 |
| HEB 600 | 600 | 300 | 17.5 | 30.0 | 212.0 |
HEM – European Extra Heavy Columns
| Section | Height h (mm) | Width b (mm) | Web Thickness tw (mm) | Flange Thickness tf (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEM 100 | 120 | 106 | 12.0 | 20.0 | 41.8 |
| HEM 120 | 140 | 126 | 12.5 | 21.0 | 52.1 |
| HEM 140 | 160 | 146 | 13.0 | 22.0 | 63.2 |
| HEM 160 | 180 | 166 | 14.0 | 23.0 | 76.2 |
| HEM 180 | 200 | 186 | 14.5 | 24.0 | 88.9 |
| HEM 200 | 220 | 206 | 15.0 | 25.0 | 103.0 |
| HEM 220 | 240 | 226 | 15.5 | 26.0 | 117.0 |
| HEM 240 | 270 | 248 | 18.0 | 32.0 | 157.0 |
| HEM 260 | 290 | 268 | 18.0 | 32.5 | 172.0 |
| HEM 280 | 310 | 288 | 18.5 | 33.0 | 189.0 |
| HEM 300 | 340 | 310 | 21.0 | 39.0 | 238.0 |
| HEM 320 | 359 | 309 | 21.0 | 40.0 | 245.0 |
| HEM 360 | 377 | 309 | 21.0 | 40.0 | 256.0 |
| HEM 400 | 432 | 307 | 21.0 | 40.0 | 268.0 |
| HEM 500 | 524 | 306 | 21.0 | 40.0 | 290.0 |
| HEM 600 | 618 | 310 | 21.0 | 40.0 | 301.0 |
HEAA – European Light Wide Flange Sections
| Section | Height h (mm) | Width b (mm) | Web Thickness tw (mm) | Flange Thickness tf (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEAA 100 | 91 | 100 | 4.5 | 5.0 | 12.2 |
| HEAA 120 | 109 | 120 | 4.5 | 5.0 | 14.7 |
| HEAA 140 | 128 | 140 | 4.5 | 6.0 | 18.1 |
| HEAA 160 | 152 | 160 | 5.0 | 6.0 | 23.8 |
| HEAA 180 | 171 | 180 | 5.0 | 6.0 | 27.1 |
| HEAA 200 | 190 | 200 | 5.5 | 6.5 | 31.2 |
| HEAA 220 | 210 | 220 | 5.5 | 7.0 | 36.2 |
| HEAA 240 | 230 | 240 | 6.0 | 7.5 | 43.0 |
| HEAA 260 | 250 | 260 | 6.0 | 7.5 | 48.0 |
| HEAA 280 | 270 | 280 | 6.5 | 8.0 | 55.0 |
| HEAA 300 | 290 | 300 | 6.5 | 8.5 | 62.0 |
Grades Available
European Structural Columns can be supplied in different structural steel grades according to applicable European Standards (EN) and project specifications. The selected grade depends on the required mechanical properties, structural loading, column dimensions, fabrication requirements and engineering design.
At Moksh Tubes & Fittings LLP, European Structural Columns can be sourced according to the customer's specified column designation, grade, dimensions, thickness, length, quantity and applicable EN requirements, subject to product availability.
Common EN Structural Steel Grades
| Grade / Specification | Material Type | Typical Requirement |
|---|---|---|
| S235JR | Non-Alloy Structural Steel | General structural and fabrication applications |
| S275JR | Non-Alloy Structural Steel | Structural applications requiring higher strength |
| S355JR | Non-Alloy Structural Steel | Higher-strength structural applications |
| S355J2 | Non-Alloy Structural Steel | Structural applications requiring specified impact properties |
| Other EN Grades | Structural Steel | As per project specification and requirement |
S235JR
S235JR is a commonly specified European structural steel grade used for general construction, fabrication and engineering applications where the specified material properties meet the project requirements.
S275JR
S275JR is a structural steel grade with higher specified yield strength than S235-grade steel and can be considered for structural column applications according to the applicable EN specification and project requirements.
S355JR
S355JR is a higher-strength structural steel grade used for structural applications where increased specified strength is required, subject to the applicable EN specification and engineering design.
S355J2
S355J2 is a structural steel grade with specified impact properties and can be considered for applications where the project specification requires the relevant mechanical and impact requirements.
Grade Selection
The appropriate grade for a European Structural Column should be selected based on:
- Required mechanical properties
- Axial and structural loading
- Column height
- Section dimensions
- Structural stability requirements
- Design requirements
- Fabrication requirements
- Welding requirements
- Applicable EN standard
- Project specification
- Required impact properties, where applicable
Customers should specify the required EN grade, column designation, section dimensions, length and quantity when submitting an enquiry.
Material Documentation
Where required and agreed at the time of order, applicable material test certificates and supporting documentation can be provided according to the purchase order and project requirements.
Applications
European Structural Columns are widely used in construction, industrial structures, infrastructure, warehouses and engineering projects where strong vertical load-bearing and structural support members are required.
Building & Construction
European Structural Columns are commonly used in building projects for commercial buildings, industrial buildings, steel-framed structures, multi-level structural frameworks, and load-bearing structural systems.
Industrial Structures
Structural columns are widely used in industrial facilities where vertical steel members are required to support structural loads. Applications include factory buildings, manufacturing facilities, industrial sheds, equipment support structures, and heavy-duty steel frameworks.
Warehouses & Storage Facilities
European Structural Columns can be incorporated into warehouse and storage structures as part of the main vertical framework. Applications include warehouse structures, industrial storage buildings, steel building frameworks, and roof-support systems.
Infrastructure Projects
Structural columns can be used in infrastructure and civil engineering projects where the specified EN section and material grade meet the project requirements. Applications include infrastructure frameworks, elevated structures, supporting structures, platforms, and engineering structures.
Heavy Structural Fabrication
European Structural Columns are suitable for fabricated steel structures requiring vertical load-bearing members. Applications include structural frames, support structures, heavy fabricated assemblies, industrial platforms, and steel frameworks.
Machinery & Equipment Supports
Structural columns can form part of support frameworks for industrial machinery and equipment, subject to the required structural design and loading conditions.
Platforms & Supporting Structures
European Structural Columns can be incorporated into industrial platforms, elevated structures and supporting frameworks where the selected section provides the required structural properties.
Steel Building Frameworks
Structural columns can be combined with European Structural Beams, Channels, Angles and Hollow Sections to create complete steel building and industrial frameworks.
The appropriate column designation, dimensions and material grade should always be selected according to the structural loading, column height, stability requirements, applicable EN standard and project specifications.
Uses of European Structural Columns
European Structural Columns are versatile structural steel members used for vertical load-bearing, structural support and steel framework applications across construction, industrial, infrastructure and engineering projects.
Used for main vertical support members in commercial, industrial and steel building structures.
Suitable for industrial sheds and factory buildings requiring structural steel column sections.
Used in warehouses and storage facilities as part of the main structural framework.
Suitable for multi-level steel structures where structural columns are specified according to engineering design.
Used for heavy-duty structural frameworks and fabricated steel structures.
Suitable for machinery and equipment support structures in industrial facilities.
Used for platforms, elevated structures and supporting frameworks according to project requirements.
Suitable for infrastructure and civil engineering projects requiring EN-specified structural steel sections.
Used for general structural fabrication, including frames, supports and steel assemblies.
Suitable for load-bearing applications where the selected column section meets the required structural design and section-property requirements.
Can be combined with European Structural Beams, Channels, Angles and Hollow Sections to create complete steel frameworks.
Available in profiles such as HEA, HEB and HEM, providing flexibility for different structural loading and support requirements.
The appropriate column designation, dimensions, grade and length should be selected according to the structural loading, column height, stability requirements, section properties, applicable EN standard and project specifications.
Advantages of European Structural Columns
European Structural Columns provide a reliable structural steel solution for vertical load-bearing, structural support and steel framework applications across construction, industrial, infrastructure and engineering projects.
High Load-Bearing Capability
Suitable for vertical structural support when the appropriate section is selected according to engineering design.
Structural Strength & Rigidity
Properly selected column sections provide the required strength and rigidity for structural frameworks.
HEA, HEB & HEM Options
Different European H-shaped column profiles provide flexibility for various structural loading and support requirements.
Wide Application Range
Suitable for commercial buildings, industrial facilities, warehouses, infrastructure, platforms and engineered structures.
EN Grade Options
Grades such as S235JR, S275JR, S355JR and S355J2 can be considered according to applicable EN specifications and project requirements.
Standard-Based Selection
Column sections can be selected according to applicable EN standards, section dimensions, material grade and engineering requirements.
Different Section Sizes
Available in different section depths, flange widths and thicknesses according to applicable European section standards and product range.
Design Flexibility
HEA, HEB and HEM profiles allow engineers to select suitable sections according to loading, column height and structural configuration.
Suitable for Heavy Structures
Appropriate column sections can be considered for industrial buildings, warehouses and other heavy structural applications.
Fabrication Friendly
Suitable for common fabrication operations such as cutting, drilling, welding and assembly, subject to applicable material and project specifications.
Project-Based Supply
Requirements can be specified according to column designation, dimensions, grade, length and quantity.
Compatible with Other European Sections
Can be used with European Structural Angles, Channels, Beams and Hollow Sections to create complete steel frameworks.
Domestic & International Applications
Suitable for projects requiring structural steel columns specified to applicable EN requirements.
The appropriate column designation and section should always be selected according to the structural loading, column height, stability requirements, section properties, applicable EN standard and project specifications.
Mechanical Properties – European Structural Columns
(Typical minimum values for common EN 10025-2 structural steel grades; values depend on product thickness.)
| Standard / Grade | S235JR | S275JR | S355JR | S355J2 |
|---|---|---|---|---|
| Tensile Strength (MPa), Min. | 360 | 370 | 470 | 470 |
| Yield Strength (MPa), ≤16 mm | 235 | 275 | 355 | 355 |
| Elongation (%), Min. | 26 | 23 | 22 | 22 |
Why Choose Moksh Tubes & Fittings LLP?
Moksh Tubes & Fittings LLP supports customers looking for European Structural Columns for construction, industrial, infrastructure, fabrication and engineering requirements. Our supply approach is based on the customer's required column designation, dimensions, grade, length, quantity and applicable EN specifications.
FAQ – European Structural Columns
What are European Structural Columns?
European Structural Columns are structural steel sections primarily used as vertical load-bearing and supporting members in buildings, industrial facilities, warehouses, infrastructure and engineered steel structures.
What types of European Structural Columns are available?
Common European column profiles include HEA, HEB and HEM, along with other applicable H-shaped structural sections.
What are HEA Columns used for?
HEA sections are commonly used as structural columns and load-bearing members in commercial buildings, industrial structures, warehouses and steel frameworks where the selected section meets the engineering requirements.
What are HEB Columns used for?
HEB sections are heavier H-shaped structural sections commonly used where greater section capacity and rigidity are required according to structural design.
What are HEM Columns used for?
HEM sections are heavier European H-shaped sections that can be considered for applications requiring substantial structural capacity and stiffness, subject to engineering design.
Which standards apply to European Structural Columns?
European Structural Columns can be specified according to applicable European Standards (EN) and the requirements stated in the project specification.
Which EN grades are available?
Grades such as S235JR, S275JR, S355JR and S355J2 may be considered according to the applicable EN specification and project requirements. Exact availability should be confirmed at the time of enquiry.
What sizes of European Structural Columns are available?
Columns are available in different section depths, flange widths, web thicknesses and flange thicknesses. Actual availability depends on the applicable EN section tables and Moksh Tubes & Fittings LLP's current product range.
Can European Structural Columns be supplied in custom lengths?
Yes. Standard and cut-to-length requirements can be considered depending on product availability and customer specifications.
How do I select the right European Structural Column?
Selection should consider the column designation, axial loading, column height, section properties, dimensions, material grade, structural stability, connection requirements and applicable EN standards.
Can Moksh Tubes & Fittings LLP supply European Structural Columns in bulk?
Yes. Moksh Tubes & Fittings LLP can support bulk and project-based requirements, subject to product availability and agreed specifications.
What information is required for a quotation?
Customers should provide the column designation, section dimensions, EN grade, required length and quantity. Project drawings or technical specifications can also be shared.
Can European Structural Columns be used with other European structural sections?
Yes. They can be used with European Structural Angles, Channels, Beams and Hollow Sections to create complete steel building frameworks and fabricated assemblies.
Does Moksh Tubes & Fittings LLP support international enquiries?
Yes. International enquiries for European Structural Columns can be discussed based on the required EN specification, column section, dimensions, quantity and delivery requirements.
Request a Quote
Looking for European Structural Columns for your construction, industrial, infrastructure or fabrication project?
Contact Moksh Tubes & Fittings LLP for European Structural Column requirements based on your required column designation, section dimensions, EN grade, length and quantity.
Share your project specifications, drawings or material requirements with our team to discuss the suitable European Structural Columns for your application.
📞 Contact Moksh Tubes & Fittings LLP at +91 97695 84950 for product availability, technical specifications and quotation enquiries.
