Introduction to Hastelloy C276 / Alloy C276 / UNS N10276
Hastelloy C276 is one of the world's most widely used corrosion-resistant nickel alloys. Its unique combination of nickel, molybdenum, chromium, tungsten, and iron provides exceptional resistance to both oxidizing and reducing chemicals, making it suitable for applications where conventional stainless steels fail.
The alloy performs exceptionally well under harsh operating conditions involving hydrochloric acid, sulfuric acid, wet chlorine, ferric chloride, seawater, acidic gases, and chloride-containing solutions. It also exhibits excellent resistance to pitting corrosion, crevice corrosion, stress corrosion cracking, and localized corrosion.
Besides its outstanding corrosion resistance, Hastelloy C276 offers excellent weldability, high ductility, superior mechanical strength, and long service life even at elevated temperatures. These characteristics make it an ideal material for pressure vessels, reactors, heat exchangers, piping systems, scrubbers, storage tanks, valves, and other critical process equipment.
Today, engineers, project consultants, EPC contractors, and procurement professionals across industries rely on Hastelloy C276 supplied by Moksh Tubes & Fittings LLP whenever equipment must operate continuously in aggressive environments without compromising safety or performance.
Download Hastelloy C276 Technical Datasheet
Need complete technical information before purchasing? Download the official Hastelloy C276 datasheet containing chemical composition, mechanical & physical properties, equivalent grades, ASTM standards, product forms, welding guidelines, and applications.
We respect your privacy. Your email will only be used to send the datasheet.
Material Specifications
| Property | Details |
|---|---|
| Material Name | Hastelloy C276 |
| Alloy Name | Alloy C276 |
| UNS Number | N10276 |
| Werkstoff Number | 2.4819 |
| Material Family | Nickel-Chromium-Molybdenum Alloy |
| ASTM Specification | ASTM B575, ASTM B622, ASTM B619, ASTM B626 |
| ASME Specification | SB575, SB622, SB619, SB626 |
| DIN Standard | DIN 17744 / NiMo16Cr15W |
| EN Standard | EN 2.4819 |
| ISO Standard | Available |
| Density | 8.89 g/cm³ (8890 kg/m³) |
| Melting Range | 1325–1370°C (2417–2498°F) |
| Magnetic Property | Non-Magnetic |
| Weldability & Corrosion Resistance | Excellent |
Chemical Composition & Equivalent Grades
The exceptional corrosion resistance of Hastelloy C276 comes from its carefully balanced nickel-rich composition. Nickel provides the primary corrosion resistance, while chromium protects against oxidizing environments. Molybdenum enhances resistance against reducing acids and pitting corrosion, whereas tungsten further improves resistance in highly aggressive chemical media.
Chemical Composition (%)
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | Balance |
| Chromium (Cr) | 14.5 – 16.5 |
| Molybdenum (Mo) | 15.0 – 17.0 |
| Iron (Fe) | 4.0 – 7.0 |
| Tungsten (W) | 3.0 – 4.5 |
| Cobalt (Co) | Maximum 2.5 |
| Manganese (Mn) | Maximum 1.0 |
| Vanadium (V) | Maximum 0.35 |
| Silicon (Si) | Maximum 0.08 |
| Carbon (C) | Maximum 0.01 |
| Copper (Cu) | Maximum 0.5 |
| Phosphorus (P) | Maximum 0.04 |
| Sulfur (S) | Maximum 0.03 |
Equivalent Grades
| Standard | Grade / Designation |
|---|---|
| UNS | N10276 |
| Werkstoff / EN | 2.4819 |
| DIN | NiMo16Cr15W |
| ASTM Plate / Sheet | ASTM B575 |
| ASTM Pipe | ASTM B622 |
| ASTM Tube | ASTM B619 |
| ASME Plate / Sheet | ASME SB575 |
| ASME Pipe | ASME SB622 |
| ASME Tube | ASME SB619 |
| ISO | International Equivalent Available |
Why is this Composition & Standard Important?
- ✔ Excellent resistance to aggressive chemicals & chloride attack
- ✔ Outstanding pitting and stress corrosion cracking resistance
- ✔ Suitable for both oxidizing and reducing acid environments
- ✔ Simplifies global procurement and standardizes international specs
Mechanical Properties of Hastelloy C276 (UNS N10276) (Annealed)
| Temperature | Tensile Strength (MPa) | Yield Strength (MPa) | Hardness (BHN) |
|---|---|---|---|
| 25 °C (80 °F) | 379 | 207 | 145 |
| 425 °C (800 °F) | ~207 | ~124 | ~100 |
| 540 °C (1000 °F) | ~172 | ~103 | ~90 |
| 650 °C (1200 °F) | ~138 | ~83 | ~85 |
| 705 °C (1300 °F) | ~124 | ~69 | ~80 |
| 760 °C (1400 °F) | ~117 | ~62 | ~75 |
Products In Hastelloy C276
MOKSH TUBES & FITTINGS LLP, with years of expertise in nickel-based alloys and an extensive global supply network, offers a complete range HASTELLOY products. These products are engineered to perform in the most corrosive environments found across industries such as Chemical Processing, Pollution Control, Oil & Gas, Marine, Power Generation, Wastewater Treatment, and more. The unique chemical composition of C276 makes it capable of resisting a wide variety of complex and mixed chemical conditions, delivering unmatched durability and reliability for mission-critical applications.
We offer Hastelloy C276 in a wide range of product forms, including:
Uses and Advantages
Excellent Corrosion Resistance in acids like hydrochloric, sulfuric, nitric, and organic acids
Good Strength and Toughness at room and elevated temperatures
Easily Weldable and Formable—supports complex fabrication
Low Reactivity with Process Media—ideal for sensitive applications
Non-toxic and Biocompatible—used in medical and high-purity chemical systems
Applications & Industries Served
| Industry Sector | Typical Hastelloy C276 Applications |
|---|---|
| Chemical Processing | Chemical Reactors, Columns, Heat Exchangers, Acid Transfer Scrubbers |
| Oil, Gas & Petrochemical | Downhole Equipment, Pipelines, Valves, Manifolds, Pressure Vessels, Storage Tanks |
| Marine & Offshore Platforms | Seawater Systems, Condensers, Structural Components, Subsea Pumps & Valves |
| Pharmaceutical & Food | Sterile Mixing Tanks, Clean Room Processing Equipment, Hygienic Process Lines |
| Power & Nuclear Industry | Boilers, Heat Exchangers, Condensers, Nuclear Reactor Components |
| Pollution Control & Paper | FGD Scrubbers, Ducting Systems, Pulp Bleaching Equipment, Digesters |
| Desalination & Aerospace | High-Pressure Seawater Handling Equipment, Elevated Temperature Components |
WHY CHOOSE US?
Frequently Asked Questions (FAQs)
What is Hastelloy C276?
Hastelloy C276, also called Alloy C276 or UNS N10276, is a nickel-chromium-molybdenum alloy known for high corrosion resistance.
What is the density of Hastelloy C276?
The density is 8.89 g/cm³, higher than mild steel or carbon steel.
What products are available in Hastelloy C276?
Pipes, tubes, sheets, plates, coils, round bars, flat bars, flanges, fasteners, and custom fabricated components.
What is the price of Hastelloy C276 in India?
Price varies based on form, quantity, and market conditions. Contact Moksh Tubes & Fittings LLP for a quote.
Can Hastelloy C276 be welded?
Yes, low carbon and silicon content ensures easy welding suitable for critical applications.
Looking for a Reliable Hastelloy C276 Supplier?
Whether you require pipes, tubes, sheets, plates, bars, flanges, fittings, fasteners, or custom-fabricated components, Moksh Tubes & Fittings LLP is your trusted partner for certified high-quality nickel alloy products.
📞 Call: +91 97695 84950 | ✉️ Email Sales Team
ISO Certified Quality | Mill Test Certificates (EN 10204 3.1) | Fast Worldwide Delivery
