Product Overview
Introduction To Nickel 200 / Alloy 200 / UNS N02200
MOKSH TUBES & FITTINGS LLP is a trusted supplier, exporter, importer, and stockist of a wide range of NICKEL 200 products including Pipes & Tubes, Pipe Fittings, Flanges, Fasteners, Sheets & Plates, Coils, Wires, Round Bars, Flat Bars, Angles, Channels, Welding Rods, Wire Mesh, and other Custom and Hard-to-Find Nickel 200 Components.
Nickel 200, is a commercially pure wrought nickel alloy (99.6% Ni) that offers excellent resistance to a wide range of corrosive environments. It exhibits outstanding mechanical properties and exceptional resistance to alkaline media, especially in caustic soda and other strongly alkaline solutions. This solid-solution strengthened alloy is highly ductile, making it ideal for both hot and cold working, and is particularly suited for applications requiring high thermal and electrical conductivity.
Download Nickel Based Superalloys 200 Datasheet
Get the complete Nickel Based Superalloys 200 datasheet with chemical composition, mechanical properties, heat treatment details, and applications. Enter your email to receive the PDF instantly.
We respect your privacy. Your email will only be used to send the datasheet.
Nickel 200 Specifications
| Category | Details |
|---|---|
| Grade | Nickel 200 / Alloy 200 / UNS N02200 |
| Material Type | Commercially Pure Nickel |
| Purity | ≥ 99.0% Nickel |
| Carbon Content | ≤ 0.15% |
| Forms Available | Pipes, Tubes, Plates, Bars, Coils, Fittings, Flanges, Fasteners |
| Conditions | Annealed / Cold Worked / Stress-Relieved |
| Testing | PMI, Tensile, Hardness, Corrosion Test |
| Certification | EN 10204 3.1 / 3.2 |
Chemical Composition of Nickel 200
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 99.0 min |
| Copper (Cu) | 0.25 max |
| Iron (Fe) | 0.40 max |
| Manganese (Mn) | 0.35 max |
| Silicon (Si) | 0.35 max |
| Carbon (C) | 0.15 max |
| Sulfur (S) | 0.01 max |
Nickel 200 offers high purity + high conductivity → ideal for electronics, food processing & chemical media.
Technical Composition of Nickel 200
Physical Properties of Nickel 200
| Property | Imperial | Metric |
|---|---|---|
| Density | 0.321 lb/in³ | 8.89 g/cm³ |
| Melting Range | 2615–2635 °F | 1435–1446 °C |
| Specific Heat | 0.109 Btu/lb·°F | 456 J/kg·°C |
| Curie Temperature | 680 °F | 360 °C |
Duplex S31803 has double the strength of 304/316 stainless steel and significantly higher pitting resistance.
Mechanical Properties of Nickel 200
| Condition | Tensile Strength | Yield Strength | Hardness | Elongation |
|---|---|---|---|---|
| Rod & Bar – Hot Finished | 55–35 ksi (380–240 MPa) | 15–45 ksi (105–310 MPa) | 60–85 HB | 90–150% |
| Rod & Bar – Cold Drawn | 35–10 ksi (240–70 MPa) | 40–100 ksi (275–690 MPa) | 65–110 HB | 140–230% |
| Rod & Bar – Annealed | 55–40 ksi | 15–30 ksi | 55–75 HB | — |
| Plate – Hot Rolled | 55–35 ksi | 20–80 ksi | 55–100 HB | 100–150% |
| Plate – Annealed | 60–40 ksi | 15–40 ksi | 55–80 HB | 90–140% |
| Sheet – Hard | 15–2 ksi | 70–105 ksi | 90–115 HB | — |
| Sheet – Annealed | 55–40 ksi | 15–30 ksi | 55–75 HB | — |
| Strip – Spring | 15–2 ksi | 70–115 ksi | 90–130 HB | — |
| Tubing – Stress Relieved | 35–15 ksi | 40–90 ksi | 65–110 HB | — |
| Tubing – Annealed | 60–40 ksi | 12–30 ksi | 55–75 HB | — |
| Wire – No.1 Temper | — | 40–75 ksi | 70–95 HRB | — |
| Wire – Spring Temper | — | 105–135 ksi | 125–145 HB | — |
International Standards & Equivalent Grades
| Product | Standards |
|---|---|
| Rods & Bars | ASTM B160, DIN 17752, ISO 9723, VdTÜV 345 |
| Pipes & Tubes | ASTM B161, B163, B725, B730 / ISO 6207 |
| Plates & Sheets | ASTM B162, DIN 17750, ISO 6208 |
| Fittings | ASTM B366 |
| Forgings | ISO 9725, DIN 17754 |
| Wire | DIN 17753, ISO 9724 |
Products in NICKEL 200
NICKEL 200 (UNS N02200 / W.Nr. 2.4066) is known for its purity and resistance to alkaline environments. It is widely used in electrical, chemical, and food processing applications due to its ability to resist corrosion and maintain strength in extreme environments.
This alloy meets several recognized industry standards, including:
Uses and Advantages
Excellent corrosion resistance in caustic and alkaline environments
High thermal and electrical conductivity
Suitable for food processing and handling due to high purity
Outstanding ductility and mechanical strength
Resistant to neutral and alkaline salt solutions
Easy to fabricate and weld using conventional techniques
Applications of Nickel 200
Nickel 200 is a preferred material in industries where purity, resistance to alkalis, and non-magnetic properties are critical. Typical applications include:
Chemical Processing
Used in tanks, vessels, and piping for caustic soda, caustic potash, and chlor-alkali production.
Electronics & Electrical
Ideal for battery components, electrical contacts, terminals, and lead wires due to its conductivity.
Food Processing
Used in handling of fatty acids, fruits, and caustic cleaning solutions.
Aerospace & Defense
Deployed in precision instrumentation and radar/electronics components.
Marine & Offshore
Corrosion-resistant fasteners and components exposed to seawater and saline atmospheres.
Heat Exchangers
Preferred in systems requiring purity and thermal conductivity under caustic conditions.
Medical Equipment
Used in equipment requiring non-reactive and clean-contact materials.
WHY CHOOSE US?
Duplex Stainless Steel S31803 Price per kg in India
Typical Range: ₹1,350 – ₹2,100 per kg
(Price varies by size, thickness, condition & quantity.)
Contact us for exact quotation based on size and quantity.
FAQ's
What is Nickel 200 and what makes it unique?
Nickel 200 (UNS N02200) is a commercially pure wrought nickel alloy containing about 99.6% nickel. It is widely recognized for its excellent resistance to alkaline and caustic environments, outstanding ductility, and high thermal and electrical conductivity. These properties make Nickel 200 an ideal choice for applications requiring both purity and performance, such as chemical processing, food handling, electronics, and marine engineering.
What types of Nickel 200 products does Moksh Tubes & Fittings LLP offer?
Moksh Tubes & Fittings LLP manufactures, supplies, and exports a wide range of Nickel 200 products including seamless and welded pipes, tubes, sheets, plates, coils, wire mesh, round bars, flat bars, angles, channels, flanges, pipe fittings, fasteners, welding rods, and custom-fabricated components. All products meet global industry standards and can be customized to meet specific client requirements across diverse industries.
What are the key benefits of using Nickel 200 in industrial applications?
The main advantages of Nickel 200 include excellent corrosion resistance in caustic and alkaline environments, superior thermal and electrical conductivity, high purity that makes it suitable for food and pharmaceutical industries, and outstanding ductility that allows easy fabrication and welding. Additionally, its non-magnetic properties and mechanical strength make it a reliable material for high-performance applications in aerospace, marine, and power generation.
Which industries commonly use Nickel 200 alloy products?
Nickel 200 is widely used in industries such as chemical processing, food processing, electronics, aerospace, defense, marine, medical, and power generation. It is commonly applied in equipment like tanks, vessels, heat exchangers, piping systems, battery components, electrical contacts, caustic soda production systems, marine fasteners, instrumentation, and medical equipment where purity, durability, and corrosion resistance are critical.
Why choose Moksh Tubes & Fittings LLP for Nickel 200 supply?
Moksh Tubes & Fittings LLP is a trusted global supplier of Nickel 200 products, known for its extensive inventory, ISO certified operations, and commitment to quality assurance. With decades of expertise, advanced testing facilities, and precision machining services, the company ensures reliable supply and timely delivery of Nickel 200 materials. Their dedication to traceability, customer satisfaction, and customized solutions makes them a preferred partner for clients across industries worldwide.
